Technical Features MDL

• Compact and light, with dimensions 270 x 170 x 70 mm and weight 1,8 Kg
• HPR Function (ANKARO Headends Programmer)
• Extremely intuitive. Very easy to use
• High Resolution Spectrum with horizontal sweep and logarithmic amplitude
• Battery Duration: 2,5 hours
• TFT 5" HQ
• Provides all the measurements in a unique window
• Super advanced Data-logger
• Auto Reference Level in spectrum
• Digital Picture in MPEG-2
• Noise figure function
• Satellite Identifier
• DiSEqC motors control
• Auto identifier of the Digital carriers
• Real measurements of BER
• Simple and fast upgrading through USB 2.0
• Data transfer to the PC through USB 2.0 stick
• SatCR compatible
• Wide connectivity: USB 2.0, RS-232, A/V IN, A/V OUT
• Same user interface than the MDX series
• HDTV measures
• Constellation diagram in DVB-S/S2
